TP-LINK (TL-WA850RE) 300Mbps Wall-Plug Wifi Range Extender, 1 LAN, AP Mode

• Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly
• Miniature size and wall-mounted design make it easy to deploy and move flexibly
• Easily expand wireless coverage at a push of Range Extender button
• Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
• Tether App allows easy access and management using any mobile device
• LED Control function includes a Night Mode for peaceful sleep
• Works with any Wi-Fi router or wireless access point

Boost Your Wireless Network
Tired of Wi-Fi ’’dead zone’’? TP-Link’s range extender connects to your router wirelessly, strengthening and expanding its signal into areas it can’t on its own. The device also reduces signal interference to ensure reliable Wi-Fi coverage throughout your home or office.

Easy Setup and Flexible Placement
Press the WPS button on your router and the Range Extender button on your 850RE within 2 minutes to easily connect to the network. Once connected with an existing router, you can simply unplug and plug the TL-WA850RE back in a location for the best signal quality and coverage in your house, without needing to configure the extender again.

Ethernet Bridge
The TL-WA850RE’s single Ethernet port allows the Extender to function as a wireless adapter to connect wired devices like Blu-ray® players, gaming consoles, DVRs and Internet TVs. At the same time, the device can share the wireless network as well.

Smart Signal Indicator Light
5 signal lights show the strength of signal that TL-WA850RE receives from the existing router, which can help to find the right location to place the range extender.

BestGoodBad
It’s recommended that you choose a location where at least 3 signal light blue in order to guarantee a good performance.

Tether App for Easy Use
Use any mobile device to easily access and manage various features, including the LED Control function's Night Mode, which allows you to enjoy a more peaceful night's sleep.

Specifications

Primary Function: Range Extender

Dual Band: No

Max Wireless Transfer Rate: 300 Mbps

Max Wired Transfer Rate: 10/100 Mbps

Interface(s): 1 x 10/100M Ethernet Port (RJ45)

Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Antenna: 2 x internal

Button(s): RE (Range Extender) Button, Reset Button

Power Supply: Wall Plug

Power Consumption: About 3W

Dimensions (W x D x H): 4.3 x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)

Weatherproof: No

Frequency: 2.4~2.4835GHz

EIRP: < 20 dBm (EIRP)

Reception Sensitivity
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER

Wireless Modes: Range Extender / Access Point

Wireless Functions
WMM (Wi-Fi Multimedia)
Wireless MAC Address Filtering
Wireless Statistic
Domain Login Function

Wireless Security
64/128/152-bit WEP
WPA-PSK / WPA2-PSK

Environment (°C)
Operating Temperature: 0C~40C (32F~104F)
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Package Contents
300Mbps Universal Wireless N Range Extender TL-WA850RE
RJ-45 Ethernet Cable
Resource CD
Quick Installation Guide
