TP-Link TL-WA801N Wireless N Access Point 2.4Ghz 300Mbps, Fixed Antennas, Multi-mode Repeater, Multi-SSID, Client, Bridge with AP

TP-Link 2.4GHz 300Mbps Access Point

Maximize your network's potential with the TP-Link TL-WA801N Wireless N Access Point. Boasting a 2.4Ghz frequency and 300Mbps speed, this device features fixed antennas for stable and reliable connectivity. With multi-mode repeater, multi-SSID, client, and bridge with AP capabilities, it can adapt to any network configuration. From TP-Link, a leader in wireless technology.

Specifications

Primary Function: Access Point

Bands: N/A

Max Wireless Transfer Rate: 300 Mbps

Max Wired Transfer Rate: 10/100 Mbps

Interface(s)
1 x 10/100M Ethernet Port(RJ45)
Support Passive PoE

Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Antenna: 2 Fixed Omni-Directional Antennas

Button(s): Power On/Off, WPS, Reset

Power Supply: 9VDC / 0.6A

Dimensions: 181.6 x 129.5 x 36.2 mm

Weatherproof: No

Frequency: 2.4 GHz

Reception Sensitivity
11g 6Mbps: -90dBm
11g 54Mbps: -77dBm
11n HT20 MC7: -73dBm
11n HT40 MC7: -70dBm

Wireless Modes
AP Mode
Multi-SSID Mode
Client Mode
Range Extender Mode

Wireless Functions
Enable/Disable Wireless Radio, WMM, Short GI, AP
Isolation, Wireless Statistics, Throughput Monitor

Wireless Security: WEP, WPA/WPA2, WPA/WPA2-PSK encryptions

Quality of Service: WMM

Management: SNMP

Advanced Functions: Up to 30 meters Passive PoE is supported

Environment (°C)
Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH

Package Contents
Wireless Access Point TL-WA801N
Power Adapter
Passive PoE Power Injector
RJ45 Ethernet Cable
Quick Installation Guide
